Stainless Steel Multi-Flue Cap with Basic Lid, Outside Mount

The Outside Mount Multi-Flue Cap with Basic Lid is a proven, tried-and-tested stainless steel chimney cap. A solid chimney cap that ensures the top & inside of your chimney stays dry. Made for easy installation, it features an outside mount design that will snugly fit over your chimney. Easily installs with silicone and masonry screws (included).

The Outside Mount cap is equipped with a 2" horizontal skirt that provides a ledge for the cap to be supported by the outside edge of the chimney. Features a 3" vertical skirt extending down each side of the chimney, allowing you to attach the cap to the sides of the chimney. The vertical side skirt has a drip edge to help divert rainwater from running straight down the chimney sides.

Moreover, the lid of the stainless steel chimney cap is removable with locking nuts. This allows you to easily access and clean the chimney flues. The Outside Mount cap has a 2" lid overhang from the mesh screen.

Installation

With a 3" vertical skirt, you will be able to easily install your new stainless steel chimney cap on the exterior perimeter of the brick chimney. Add a bead of silicone on the inner skirt panel and simply slide the outside mount cap over the chimney.

Using the drill bit, pre-drill the pilot holes through the skirt panel and into the chimney. Secure the cap with masonry screws and silicone. Depending on cap size, we recommend adding 2-3 masonry screws evenly spaced along the sides of the cap. That usually works out to be 18 to 24 inches between masonry screws.

With the measurements you provide, we will fabricate the cap for a perfect fit. Removable lid for easy access, cleanings, and maintenance. Features a lid overhang of 2" on all sides of the mesh screen.

Why Choose Our Stainless Steel Chimney Cap

When choosing a multi-flue chimney cap, stainless steel is the best option. You are choosing to install a chimney cap that will last a lifetime, never rust, and offer protection for your chimney.

Keeping critters, rain, snow, and debris is valuable in itself while also protecting the chimney from deterioration. Fabricated from 304 stainless steel, this stainless steel chimney cap is built to last. Backed by a lifetime warranty against rust or defects. Proudly made in the USA, you can trust the superior craftmanship and durability of our Outside Mount chimney cap.

Add beauty & curb appeal to your chimney cap by adding optional powder coating. See image swatch above for color options - Read More About Powder Coating

Measuring for Your Stainless Steel Chimney Cap

Measure your chimney to ensure a custom fit with our measuring tips. Provide your measurements and we will fabricate the stainless steel chimney cap accordingly.

Most importantly, we recommend adding at least 1/4" extra allowance to the exact length and width measurements of the brick chimney. Having this extra allowance will ensure a snug fit while also properly covering the outer bricks.

Screen height size is recommended to be at least 6" taller than the top of the flue tile. For example, if the tallest clay flue tile is 6" tall then we would like to see the screen height size at least 12" tall.

Note: Stainless Steel Knock-Down Multi-Flue Caps are made custom per order and are non-returnable. With a fabrication time of 1-2 weeks (plus an additional week for powder coating, if desired), your chimney protection solution is just around the corner.

When measuring for your Outside Mount Stainless Steel Chimney Cap, here are the things you will need to consider:

• Overall length of chimney (we recommend adding 1/4" to the exact measurement)
• Overall width of chimney (we recommend adding 1/4" to the exact measurement)
• Screen height (should be at least 6" higher than the tallest flue)
• Measuring Form (Printable PDF)
