Breckwell SW500 Wood Burning Stove
Product Images
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Breckwell SW500 Wood Burning Stove
Product Details
Specifications
Help & Documents
Options
The Breckwell SW500 Wood Burning Stove is the perfect wood stove for heating smaller spaces or homes that utilize zone heating. This space saving stove is capable of heating up to 750 square feet and is able to handle up to an 11" log size with a max burn time of up to 8 hours on one load of wood.
The Breckwell SW500 is a secondary combustion stove that has an optimum efficiency of 75% and burns clean with only a 1.7 grams per hour emissions rating which is far below the strict standards of the EPA. The sleek, modern design will fit in any decor and is sure to be the focal point of any room it is in.
The SW500 offers space underneath the stove for wood storage to accommodate tight rooms. The SW500 saves you space and money, at only $999.00 the SW500 wood stove is one of the more affordable stoves of its size. The savings do not end there! The Breckwell SW500 qualifies for the wood and pellet stove tax credit with an HHV rating higher than 75%. If you are looking for a small stove with a great design, the Breckwell SW500 is the stove for you.
Features
- Heats up to 750 Square Feet
- 11″ Log Length Capacity
- Adaptable 6″ Flue
- US Mobile Home Approved
- Ideal for Smaller Homes or Zone Heating
- Burn Time of Up To 8 Hours
- Optional Blower
- Exceeds 75% Efficiency and Qualifies for IRS 30% 25C Residential Energy Tax Credit
Measuring for Your Breckwell SW500
Stove Insert Measurement Guides
Installing Your New Wood Stove
Breckwell SW500 Wood Stove Specifications
|
Recommended heating area |
750 Square Feet |
|
Overall firebox volume |
.59 Cubic Feet |
|
Construction |
Steel |
|
Maximum burn time |
8 Hours |
|
Maximum heat output-dry cordwood |
26,000 BTUs |
|
Optimum efficiency |
75% |
|
Average particulate emission rate |
1.7 g/hr |
|
Certifications |
EPA-2020 |
|
Alcove installation approved |
Not Approved |
|
Mobile home approved |
Yes |
|
Overall dimension (Width) |
16.4" |
|
Overall dimension (Height) |
33.5" |
|
Overall dimension (Depth) |
13" |
|
Premium quality blower included (CFM) |
Optional |
|
Combustion technology |
Non catalytic |
|
Stainless-steel secondary-air system |
Yes |
|
Flue outlet diameter |
6" |
|
Recommended chimney diameter |
6" Flue |
|
Type of chimney |
CAN/ULC S629, UL 103 HT (2100 °F) |
|
Minimum chimney height |
12' |
|
Door type |
Cast Iron |
|
Door opening size (Width) |
9.6" |
|
Door opening size (Height) |
9.6" |
|
Glass type |
Pyroceramic Glass |
|
Glass surface - W x H |
9.5" x 10.5" |
|
Firebox size (Width) |
11.5" |
|
Firebox size (Depth) |
8.5" |
|
Log positioning |
East/West |
|
Maximum log length |
11" |
|
Firebox lined with refractory bricks |
Yes |
|
Weight |
120 Lbs. |
|
Door opening size (Height) |
9.6" |
|
Glass type |
Pyroceramic Glass |
|
Glass surface - W x H |
9.5" x 10.5" |
|
Firebox size (Width) |
11.5" |
|
Firebox size (Depth) |
8.5" |
|
Log positioning |
East/West |
|
Maximum log length |
11" |
|
Firebox lined with refractory bricks |
Yes |
|
Weight |
120 Lbs. |
Minimum Clearance to Combustibles
|
Clearance to Combustibles* |
Single Wall |
|
Clearance - Back Wall |
13" |
|
Clearance - Side Wall |
13" |
|
Clearance - Corner |
10" |
|
Clearance - Base of the unit to ceiling** |
84” |
Product Details:
The Breckwell SW500 Wood Burning Stove is the perfect wood stove for heating smaller spaces or homes that utilize zone heating. This space saving stove is capable of heating up to 750 square feet and is able to handle up to an 11" log size with a max burn time of up to 8 hours on one load of wood.
The Breckwell SW500 is a secondary combustion stove that has an optimum efficiency of 75% and burns clean with only a 1.7 grams per hour emissions rating which is far below the strict standards of the EPA. The sleek, modern design will fit in any decor and is sure to be the focal point of any room it is in.
The SW500 offers space underneath the stove for wood storage to accommodate tight rooms. The SW500 saves you space and money, at only $999.00 the SW500 wood stove is one of the more affordable stoves of its size. The savings do not end there! The Breckwell SW500 qualifies for the wood and pellet stove tax credit with an HHV rating higher than 75%. If you are looking for a small stove with a great design, the Breckwell SW500 is the stove for you.
Features
- Heats up to 750 Square Feet
- 11″ Log Length Capacity
- Adaptable 6″ Flue
- US Mobile Home Approved
- Ideal for Smaller Homes or Zone Heating
- Burn Time of Up To 8 Hours
- Optional Blower
- Exceeds 75% Efficiency and Qualifies for IRS 30% 25C Residential Energy Tax Credit
Measuring for Your Breckwell SW500
Stove Insert Measurement Guides
Installing Your New Wood Stove
Specifications:
Breckwell SW500 Wood Stove Specifications
|
Recommended heating area |
750 Square Feet |
|
Overall firebox volume |
.59 Cubic Feet |
|
Construction |
Steel |
|
Maximum burn time |
8 Hours |
|
Maximum heat output-dry cordwood |
26,000 BTUs |
|
Optimum efficiency |
75% |
|
Average particulate emission rate |
1.7 g/hr |
|
Certifications |
EPA-2020 |
|
Alcove installation approved |
Not Approved |
|
Mobile home approved |
Yes |
|
Overall dimension (Width) |
16.4" |
|
Overall dimension (Height) |
33.5" |
|
Overall dimension (Depth) |
13" |
|
Premium quality blower included (CFM) |
Optional |
|
Combustion technology |
Non catalytic |
|
Stainless-steel secondary-air system |
Yes |
|
Flue outlet diameter |
6" |
|
Recommended chimney diameter |
6" Flue |
|
Type of chimney |
CAN/ULC S629, UL 103 HT (2100 °F) |
|
Minimum chimney height |
12' |
|
Door type |
Cast Iron |
|
Door opening size (Width) |
9.6" |
|
Door opening size (Height) |
9.6" |
|
Glass type |
Pyroceramic Glass |
|
Glass surface - W x H |
9.5" x 10.5" |
|
Firebox size (Width) |
11.5" |
|
Firebox size (Depth) |
8.5" |
|
Log positioning |
East/West |
|
Maximum log length |
11" |
|
Firebox lined with refractory bricks |
Yes |
|
Weight |
120 Lbs. |
|
Door opening size (Height) |
9.6" |
|
Glass type |
Pyroceramic Glass |
|
Glass surface - W x H |
9.5" x 10.5" |
|
Firebox size (Width) |
11.5" |
|
Firebox size (Depth) |
8.5" |
|
Log positioning |
East/West |
|
Maximum log length |
11" |
|
Firebox lined with refractory bricks |
Yes |
|
Weight |
120 Lbs. |
Minimum Clearance to Combustibles
|
Clearance to Combustibles* |
Single Wall |
|
Clearance - Back Wall |
13" |
|
Clearance - Side Wall |
13" |
|
Clearance - Corner |
10" |
|
Clearance - Base of the unit to ceiling** |
84” |
