True North TN40 Pellet Insert
Product Images
True North TN40 Pellet Insert
True North TN40 Pellet Insert
True North TN40 Pellet Insert
Product Details
Specifications
Help & Documents
Options
Introducing the True North TN40 Pellet Insert, a remarkable heating solution designed to transform your living space with efficient and reliable warmth. This advanced pellet insert boasts an impressive heating capacity, delivering up to 36,000 BTUs to ensure your home stays cozy even during the coldest months.
Ideal for medium to large-sized areas, the TN40 effectively heats spaces up to 2,000 square feet, making it a perfect solution for supplemental heating in the cold winter months. Efficiency is at the core of the True North TN40, with an outstanding efficiency rating of 73%. This means you can enjoy more heat while using less fuel, contributing to lower energy costs and a smaller environmental footprint. The spacious hopper can hold up to 60 pounds of pellets, allowing for extended burn times and reducing the frequency of refills.
Controlling the TN40 is a breeze, thanks to its user-friendly digital control panel. This feature provides precise temperature adjustments and easy access to various settings, ensuring optimal comfort with minimal effort. The TN40 also includes automatic ignition, creating a quick and hassle free start up.
Designed to seamlessly blend with your home decor, the TN40 comes with 29" height x 42" wide surround that provides a polished and integrated look. Its sleek and modern design not only enhances the aesthetic appeal of your space while concealing the gap in between the insert and the old fireplace. A larger 32" height x 48" wide surround flashing is also available if you need to cover a larger fireplace opening.
Upgrade your heating experience with the True North TN40 Pellet Insert, where exceptional performance, efficiency, and style converge to create the ultimate home heating solution.
Features
- Mobile home approved
- Easy access digital controls
- Easy opening hopper lid for refueling with safety shut-off switch
- Clean glass air-wash technology
- Self-cleaning stainless steel burn pot liner
- EPA Certified
- Simple 3-mode operation: manual (automatic, hi/low – when equipped with a thermostat)
- Convenient 5 level heat control
- Optional wall thermostat capable operation
- Automatic igniter
- Limited Warranty
TN40 Pellet Insert Specifications
| BTU Range [EPA] | 36,000 BTU high, 8,000 BTU low |
| Efficiency | 73% |
| Emissions | 0.69g/hr. |
| Glass Viewing Area | 104 sq.in. |
| Hopper Capacity | up to 60lb. |
| Heating Area | 2000 sq. ft. |
| Volts | 120 volts, 60 Hz. |
| Amps Peak Operating | 4.3 Amps |
| Amps Normal Operating | 2.5 Amps |
| Exhaust Size | 3" |
| Blower Included | Yes |
| Minimum fireplace opening (Height) | 21 1/4" |
| Minimum fireplace opening (Width) | 29 1/2" |
| Minimum fireplace opening (Depth) | 16" |
Clearance to Combustibles
| Side of Top to Sidewall | 12" |
| Side of Top to 3-1/2" [89mm] Max. deep Mantle Side Facing | 8 1/2" |
| Top of stove to Mantle or Mantle Facing | 13" |
| Height of Ceiling above Stove's Base | 54" |
| In Front of unit | 36" |
Product Details:
Introducing the True North TN40 Pellet Insert, a remarkable heating solution designed to transform your living space with efficient and reliable warmth. This advanced pellet insert boasts an impressive heating capacity, delivering up to 36,000 BTUs to ensure your home stays cozy even during the coldest months.
Ideal for medium to large-sized areas, the TN40 effectively heats spaces up to 2,000 square feet, making it a perfect solution for supplemental heating in the cold winter months. Efficiency is at the core of the True North TN40, with an outstanding efficiency rating of 73%. This means you can enjoy more heat while using less fuel, contributing to lower energy costs and a smaller environmental footprint. The spacious hopper can hold up to 60 pounds of pellets, allowing for extended burn times and reducing the frequency of refills.
Controlling the TN40 is a breeze, thanks to its user-friendly digital control panel. This feature provides precise temperature adjustments and easy access to various settings, ensuring optimal comfort with minimal effort. The TN40 also includes automatic ignition, creating a quick and hassle free start up.
Designed to seamlessly blend with your home decor, the TN40 comes with 29" height x 42" wide surround that provides a polished and integrated look. Its sleek and modern design not only enhances the aesthetic appeal of your space while concealing the gap in between the insert and the old fireplace. A larger 32" height x 48" wide surround flashing is also available if you need to cover a larger fireplace opening.
Upgrade your heating experience with the True North TN40 Pellet Insert, where exceptional performance, efficiency, and style converge to create the ultimate home heating solution.
Features
- Mobile home approved
- Easy access digital controls
- Easy opening hopper lid for refueling with safety shut-off switch
- Clean glass air-wash technology
- Self-cleaning stainless steel burn pot liner
- EPA Certified
- Simple 3-mode operation: manual (automatic, hi/low – when equipped with a thermostat)
- Convenient 5 level heat control
- Optional wall thermostat capable operation
- Automatic igniter
- Limited Warranty
Specifications:
TN40 Pellet Insert Specifications
| BTU Range [EPA] | 36,000 BTU high, 8,000 BTU low |
| Efficiency | 73% |
| Emissions | 0.69g/hr. |
| Glass Viewing Area | 104 sq.in. |
| Hopper Capacity | up to 60lb. |
| Heating Area | 2000 sq. ft. |
| Volts | 120 volts, 60 Hz. |
| Amps Peak Operating | 4.3 Amps |
| Amps Normal Operating | 2.5 Amps |
| Exhaust Size | 3" |
| Blower Included | Yes |
| Minimum fireplace opening (Height) | 21 1/4" |
| Minimum fireplace opening (Width) | 29 1/2" |
| Minimum fireplace opening (Depth) | 16" |
Clearance to Combustibles
| Side of Top to Sidewall | 12" |
| Side of Top to 3-1/2" [89mm] Max. deep Mantle Side Facing | 8 1/2" |
| Top of stove to Mantle or Mantle Facing | 13" |
| Height of Ceiling above Stove's Base | 54" |
| In Front of unit | 36" |
